The Micro precision M1.8 flat head positioning pin is an extremely compact
Mini screw designed for high-precision alignment of 0.3 mm thin-wall modules. With an outer diameter of 1.8 mm and a flat head thickness of 0.2 mm, it can achieve tight fit without increasing the height; the imported SUS420 stainless steel is vacuum quenched to HV 520, and the surface DLC coating is rust-proof after 500 h of salt spray, ensuring zero clearance positioning in
Micro Screws applications such as micro optics and sensor housings.
As a Precision screw-level component, its cylindricality is ≤0.003 mm, coaxiality is ≤0.01 mm, and the matching hole tolerance H6 can achieve ±5 µm repeat positioning accuracy; the micro chamfer and knurl design at the end facilitates automated assembly, and the insertion and extraction force is stable between 2-4 N, meeting 10⁴ insertions and extractions without loosening.
After passing ASTM F837 certification, the pin can be directly used as a guide for
Aerospace Micro Screws for satellite laser communication modules and drone gyro brackets. It weighs only 0.006 g, but can maintain micron-level position accuracy in an environment of −55 °C~+150 °C and 30 g vibration, providing reliable ultimate positioning guarantee for lightweight spacecraft.
Yijun specializes in the production of M0.5-M3 micro Precision Screws, and supports customization of various models of M0.5-M3 for this product or other products
Product advantages
In today's industrial field, high-precision micro screws are small but play an indispensable and key role. As a leading enterprise in the industry, Shanghai Yijun focuses on the production of high-precision micro screws and is committed to providing excellent fastening solutions for various industries. With excellent product quality, a wide range of applications, and thoughtful customer service, the company has established a good reputation in the field of high-precision micro screw production and won the trust and support of many customers.
More products
The company always adheres to customer-centricity and provides customers with a full range of high-quality services. From the moment the customer raises a demand, the professional customer service team will respond quickly and communicate with the customer in depth to understand their specific needs. The technical team is fully supportive, from the development of special specification screws to the customization of surface treatment processes, providing drawing design, sample proofing, and batch production full-process services to ensure that the most suitable products are tailored for customers.
Factory display
The company has a team of senior engineers and professional technicians who have rich industry experience and superb technology, and have in-depth research and unique insights into the production process of micro screws. From the strict screening of raw materials, to every step in the production process, to the final quality inspection, the team strictly controls to ensure that every micro screw meets the highest quality standards.
